SHOE™ Railing Systems (Patented)

SHOE™ Glass Railings System is a structural glass balustrade system with a patented compression set aluminum base shoe system.

SHOE™ Structural Glass Railings are a great choice for commercial interior or exterior, balcony railing or stair railing applications. This architectural railing solution provides fall protection barrier without obstruction to view or an unsightly barrier.

SHOE™ Structural Glass Railings can be either top or fascia mounted. It is available with a glass bracket mounted handrail, round top cap or a U-channel top cap. Base shoe is available in stainless steel or an anodized aluminum cladding.

VIVA Railings dry set system reduces the installation time by almost 50%, hence a reduced final cost to the customer.

LED illumination is available in the handrail, top cap or even in the SHOE™ base. Lighting the SHOE™ base or top cap provides a glow to a glass panel. This glow becomes even more dramatic with an etched pattern or logo which catches the emitted light.

SHOE™ Glass Railing System is a structural glass balustrade system with a patented compression set aluminum base shoe system.

SHOE™ Glass Railing is a great choice for commercial interior or exterior, balcony railing or stair railing applications. This architectural railing solution provides fall protection barrier without obstruction to view or an unsightly barrier.

SHOE™ Glass Railing can be either top or fascia mounted. It is available with a glass bracket mounted handrail, round top cap or a U-channel top cap. Base shoe is available in stainless steel or a anodized aluminum cladding.

VIVA Railings dry set system reduces the installation time by almost 50%, hence a reduced final cost to customer.

LED illumination is available in handrail, top cap or even in the SHOE™ base.  Lighting the SHOE™ base or top cap, provides a glow to glass panel. This glow become even more dramatic with a etched pattern or logo which catches the emitted light.



Posts
  • DrySet (Patented) 21/2″ x 4” with clear anodized aluminum or SS cladding

  • Height – 42” or Custom

  • Top Cap – 1” Light U-Cap (non-structural); 1.66 Ø SS Cap Rail; 1.5” Heavy U-Cap; 11/2″ Ø LED iRail

  • Assist Rail – 1 1/2″ Ø SS Rail; 2” Ø Wood Rail; 1 1/2″ Ø LED iRail

  • Wall Rail – 1 1/2″ Ø SS Rail; 2” Ø Wood Rail; 1 1/2″ Ø LED iRail

Finishing Options
  • Stainless Steel – #6 Brushed Satin in SS-304 or SS-316 alloy
  • Aluminum – Clear Anodized Aluminum (cladding only)
  • Powder CoatPosts Only – 15 different shades available
  • ECM in SS-304 and SS-316 alloy (posts only) – 5 shades available

  • Wood (unstained) – Red Oak, Cherry & Maple (other species avail on request)

  • iRail – (LED illuminated Rail – 1½” Ø LED iRail available in Pure White & Warm White

Infill Options Available

  • Tempered Glass

Mounting Options Available

  • Top
  • Fascia

MIN. 1/2″ THK. TEMPERED & LAMINATED GLASS

 Clear Monolithic

clear-laminated-glass-viva-infillClear Laminated (SGP)

Bent Monolithic

Tinted

Ceramic Frit

Patterned Ceramic Frit
