SMOKE BAFFLE System
Engineered transparency for modern architecture. A certified, pre-engineered solution designed for structural integrity and versatile design adaptability.
EXECUTIVE SUMMARY
The SBS Smoke Baffle Glass System by VIVA Railings provides a seamless and inconspicuous smoke barrier solution for modern buildings. Designed to meet fire code requirements while maintaining aesthetic integrity.
Code Compliant
Meets stringent safety standards including IBC, CBC, and FBC HVHZ for windborne debris resistance.
Modular Design
Pre-engineered components and CNC fabrication reduce on-site adjustments and ensure installation efficiency.
Design Freedom
Extensive finish options, glass types, and mounting conditions to match any architectural vision.
TECHNICAL DETAILS
Engineered for performance and durability.
Mounting
SBS-1, a stainless steel clamp-mounted system or SBS-2, a two-part aluminum system with surface or concealed mounting
Glass Infill
3/8” or 1/2” tempered or laminated (PVB or SGP)
Height
18” standard, custom heights available.
Finish Options
Standard anodized and satin finishes, plus premium CeraShield™ Ceramic Coating for extreme environments.
Load Performance
Engineered to withstand uniform loads of 50 lbf/ft and concentrated loads of 200 lbf.
Certifications
ICC-ES ESR-4405, ETL Certified (illuminated options), and compliant with ASTM C1172 & C1048.
VIVA DIFFERENTIATORS
A partnership built on precision and expertise.
Pre-Engineered & Certified
Saves time in approvals and inspections with a fully certified system.
Design Assist Services
Early collaboration with architects and GCs to ensure code-compliant, cost-effective solutions.
CeraShield™ Finishing
Enhanced durability that outperforms standard powder coating in UV and corrosion tests.
Case Studies
Trusted by leading architects and contractors on landmark projects.
START YOUR PROJECT
Empower your design with engineered performance and elegance.
SBS ensures compliance with fire codes while preserving architectural design intent. SBS stands as a reliable, modern solution for smoke control in today’s buildings.
