Finishing Options

Viva logo
SS #6 Satin

#6 Satin is a silver-white finish with relatively short linear directional polishing lines.

viva logo
SS #8 Mirror

#8 Mirror is the most reflective finish covered by ASTM Standards.

Powder Coat
Powder Coat

Designed to withstand extreme temperatures, powder-coating protects against rust and staining.

Tone Finish
2-Tone Finish

For VORTEX™ Railings Systems.

PVDF
PVDF

For ECO ELLIPSE™ & ECO VISTA™

Stainless Steel – #6 Satin

#6 Satin is a silver-white finish with relatively short linear directional polishing lines. This finish is quite common with SS architectural applications. It is a two-step abrasive polish finish with the equivalent of a 240-grit abrasive.

Stainless Steel – #8 Mirror

#8 Mirror is the most reflective finish covered by ASTM Standards. Produced in a similar way as the #6 finish with further buffing. The grit lines are much less visible than the #6 finish but can be seen upon close inspection. The final product is a mirror-like finish.

*#8 Mirror Finish comes at an additional cost to our #6 Finish.

Powder Coated Finish

Looking for a pop of color on your railing system?

Powder coating is a dry film process, using finely ground particles of pigment and resin which are electrostatically charged and sprayed onto electrically grounded parts to be coated. The charged powder particles adhere to the parts and are held there until melted and fused into a uniformly flowing coating in a curing oven. Before coating, the parts must be pretreated similarly to liquid-coated parts.

Designed to withstand extreme temperatures, powder-coating protects against rust and staining, making it a weather-resistant finish for our railings. It helps in regard to LEED requirements and in addition, it meets AAMA specifications.

Powder Coated Finishing can be applied to any of the following systems:

BLADE™ | BEACON™ | CIRCA™ | CUBE™ | TEE™ | VIEW™ | SOLO™ | SHOE™ | VISIO™ | FSR™

As in all of our stainless steel railing systems, customization is always available as at VIVA Railings our priority is ensuring that what we construct perfectly matches your vision.

This color chart is for reference only and is not to be used for final color matching. Shades may vary due to the color and resolution of your computer screen and/or your particular color printer output. For accurate color matching, please request a sample at vivarailings.com/contact.

DISCLAIMER

This color chart is for reference only and is not to be used for final color matching. Shades may vary due to the color and resolution of your computer screen and/or your particular color printer output. For accurate color matching, please request a sample at vivarailings.com/contact.

2-Tone Finish

VORTEX™ Glass Railing System can be applied as a combination of Type A/Type B finishing option.

Type A: Powder Coat Post with SS Fittings.
Type B: Powder Coat Fittings with SS Posts.

PVDF Finish

PVDF coating is chemical resistant, thick film barrier coating primarily used due to its low thermal conductivity. This coating is unaffected by most chemicals and solvents and has excellent wear and abrasion resistance. PVDF resin is polyvinylidene fluoride used as the base resin in liquid paint coatings formulated by paint manufacturers. PVDF coatings are factory applied to properly cleaned, pre-treated and primed metal substrates and then oven-baked.

PVDF Finishing can be applied to any of the following systems:

ECO VISTA™ | ECO ELLIPSE™
